Bollards

Dabmar Lighting

D820-LB60-40K Series

Projekt Ref. PS-BLD-F000022

Cast Aluminum Bollard Tilting 120V-277V LB 60W 40K

See other Dabmar Lighting bollards

Configure your fixture

3 configurations available

Finish

Wattage

Color temperature

40K
WarmCool
D820-LB60-40K Specification Sheet

WARNING: Cancer and Reproductive Harm — www.P65Warnings.ca.gov

Model Options

In Stock
D820-LB60-40K-VGD820-LB60-40K-BD820-LB60-40K-BZ

Add to cart to check out. Sign in to save a project after adding items.

D820-LB60-40K-B

Projekt: PS-BLD-000605

60W · 120V-277V · Black

Projekt Supply Price

$679.50

Save 25%

List Price
$906.00
Availability
In Stock
Color temp
40K
Wattage
60W

D820-LB60-40K-BZ

Projekt: PS-BLD-000606

60W · 120V-277V · Bronze

Projekt Supply Price

$679.50

Save 25%

List Price
$906.00
Availability
In Stock
Color temp
40K
Wattage
60W

D820-LB60-40K-VG

Projekt: PS-BLD-000530

60W · 120V-277V · Verde Green

Projekt Supply Price

$931.50

Save 25%

List Price
$1,242.00
Availability
In Stock
Color temp
40K
Wattage
60W
ModelWattageVoltageColor TempFinishList PriceProjekt Supply PriceAvailability
Qty
D820-LB60-40K-BProjekt: PS-BLD-00060560W120V-277V40KBlack$906.00

$679.50

Save 25%

In Stock
D820-LB60-40K-BZProjekt: PS-BLD-00060660W120V-277V40KBronze$906.00

$679.50

Save 25%

In Stock
D820-LB60-40K-VGProjekt: PS-BLD-00053060W120V-277V40KVerde Green$1,242.00

$931.50

Save 25%

In Stock

Selected finish

Family preview

Image gallery

Application & selection guidance

The D820-LB60-40K series is an integral-led architectural bollard for pedestrian paths, walkways, driveways, and entrance areas. Choose it when you want that path-light form to mark circulation, not a well or a directional spotlight.

Best for

  • Pedestrian Paths
  • Walkways
  • Driveways
  • Entrance Areas
  • Commercial Landscape
  • Residential

Family specification below. Select an exact configuration above to pin model-specific values.

Family specification

Technical Specifications

+−

Family facts apply across D820-LB60-40K unless a selected configuration above says otherwise.

28.56"

Overall Height

13.00"

Max Width

Cast Aluminum

Body Material

Wet Location

UL Approved

Surface Mount

Mounting Type

Physical

Overall dimensions
13.00" W × 28.56" H × 5.22" D
Overall height
28.56"
Width
13.00"
Maximum depth
5.22"
Body material
Cast Aluminum
Lens
Heat-resistant polycarbonate
Mounting type
Surface Mount

Finish / Construction

Body

Optical / application notes

  • Confirm glare/uplight suitability for dark-sky-sensitive projects.
  • Consult Projekt Supply for lamp-specific performance/IES data.

Family range

Light Source & Configuration

+−

This is a technical summary of the D820-LB60-40K range. Use Model Options above for pricing, availability, and ordering.

Source types

  • LED

Wattages

  • 60W

Color temperatures

  • 4000K

Lamp bases

  • E26

Voltage varies by configuration. Not every D820-LB60-40K configuration supports every listed voltage.

Observed voltages: 120V-277V

Configuration performance

Lumens shown are manufacturer fixture values for D820-LB60-40K where verified.

Installation

Mounting & Installation

+−
D820-LB60-40K mounting drawing

Dimensions shown in inches; metric equivalents shown where supplied by manufacturer.

Installation notes

  • Surface mount.
  • Use the manufacturer template and anchor pattern shown.
  • Confirm mounting hardware with the current manufacturer kit.
  • Field wiring and anchorage to comply with local code.
  • Verify substrate and site conditions before installation.

These notes summarize the specification drawing. They do not replace manufacturer installation instructions, a licensed electrician, or an engineer’s review of site conditions.

Project resources

Documents, Photometrics & Warranty

+−

Specification sheet

D820-LB60-40K Product Specification

PDF · 3 pages

Download specification sheet

Installation / mounting drawing

Mounting drawing

Shown on this page. No separate installation PDF is currently published in the catalog.

Photometrics / IES

Lamp-specific performance

Contact Projekt Supply for lamp-specific performance / IES data.

Contact Projekt Supply

Warranty

  • Cast Aluminum: 3 years from date of shipment.
  • LED: refer to current manufacturer lamp warranty and performance data.
Cast Aluminum
Lens
Heat-resistant polycarbonate
Finishes
Black (-B), Bronze (-BZ), Verde Green (-VG)
Construction
Cast Aluminum body.
Construction
Integral LED board; lamp is not field-replaceable.
Construction
Heat-resistant polycarbonate lens/diffuser.

Listing

Listing
UL Approved for Wet Location

Electrical

Family voltage range
120V-277V
Lamp bases
E26
Note
Integral LED driver on LED configurations.
Note
Integral LED board; no screw-in lamp.
Note
LED source included on LED configurations.
ConfigurationRated outputVoltageCCTNominal lumensBase
D820-LB60-40K60W120V-277V4000K7500 lmE26

How to order

Add -B for Black or -BZ for Bronze or -VG for Verde Green to complete the model number.

D820-LB60-40K-B

60W / 40K / Black

The Model Options table above remains the ordering interface.

Manufacturer

Dabmar Lighting Incorporated

Projekt Supply is the seller and authorized reseller. Dabmar Lighting Incorporated is the manufacturer.

Sold by Projekt Supply.

Selection / technical help
