D700-SS316 Product Specification
PDF · 3 pages
Download specification sheetProjekt Ref. PS-BLD-F000018
Stainless 316 Bollard Caged 120V-277V E26 No Lamp
See other Dabmar Lighting bollards
Need help choosing a bollard? Read our bollard selection guide.
Configure your fixture
11 configurations available
WARNING: Cancer and Reproductive Harm — www.P65Warnings.ca.gov
Add to cart to check out. Sign in to save a project after adding items.
Projekt Supply Price
$810.00
Save 25%
Projekt Supply Price
$826.50
Save 25%
Projekt Supply Price
$826.50
Save 25%
Projekt Supply Price
$850.50
Save 25%
Projekt Supply Price
$850.50
Save 25%
Projekt Supply Price
$850.50
Save 25%
Projekt Supply Price
$922.50
Save 25%
Projekt Supply Price
$922.50
Save 25%
Projekt Supply Price
$922.50
Save 25%
Projekt Supply Price
$972.00
Save 25%
Projekt Supply Price
$972.00
Save 25%
| Model | Wattage | Voltage | Color Temp | Finish | List Price | Projekt Supply Price | Availability | Qty |
|---|---|---|---|---|---|---|---|---|
| D700-SS316Projekt: PS-BLD-000600 | Non-LED | 120V-277V | N/A | Stainless Steel 316 | $1,080.00 | $810.00 Save 25% | In Stock | |
| D700-L6-30K-SS316Projekt: PS-BLD-000483 | 6W | 120V | 30K | Stainless Steel 316 | $1,102.00 | $826.50 Save 25% | In Stock | |
| D700-L6-60K-SS316Projekt: PS-BLD-000484 | 6W | 120V | 60K | Stainless Steel 316 | $1,102.00 | $826.50 Save 25% | In Stock | |
| D700-L6-RGBW-SS316Projekt: PS-BLD-000485 | 6W | 86V-265V | RGBW | Stainless Steel 316 | $1,134.00 | $850.50 Save 25% | In Stock | |
| D700-L9-27K-SS316Projekt: PS-BLD-000486 | 9W | 120V | 27K | Stainless Steel 316 | $1,134.00 | $850.50 Save 25% | In Stock | |
| D700-L9-40K-SS316Projekt: PS-BLD-000487 | 9W | 120V | 40K | Stainless Steel 316 | $1,134.00 | $850.50 Save 25% | In Stock | |
| D700-L12-30K-SS316Projekt: PS-BLD-000478 | 12W | 120V-277V | 30K | Stainless Steel 316 | $1,230.00 | $922.50 Save 25% | In Stock | |
| D700-L12-40K-SS316Projekt: PS-BLD-000479 | 12W | 120V-277V | 40K | Stainless Steel 316 | $1,230.00 | $922.50 Save 25% | In Stock | |
| D700-L12-50K-SS316Projekt: PS-BLD-000480 | 12W | 120V-277V | 50K | Stainless Steel 316 | $1,230.00 | $922.50 Save 25% | In Stock | |
| D700-L20-30K-SS316Projekt: PS-BLD-000481 | 20W | 120V-277V | 30K | Stainless Steel 316 | $1,296.00 | $972.00 Save 25% | In Stock | |
| D700-L20-50K-SS316Projekt: PS-BLD-000482 | 20W | 120V-277V | 50K | Stainless Steel 316 | $1,296.00 | $972.00 Save 25% | In Stock |
Selected finish
Stainless Steel 316
Image gallery
D700-SS316 is a caged 316 stainless-steel bollard for pedestrian-scale site lighting. Choose it when the stainless body is the reason to specify this series, not a fiberglass or aluminum path bollard. The caged head is more open than a louvered or shuttered bollard.
Family specification below. Select an exact configuration above to pin model-specific values.
Family specification
Family facts apply across D700-SS316 unless a selected configuration above says otherwise.
42.44"
Overall Height
8.72"
Max Width
Stainless Steel 316
Body Material
Wet Location
UL Approved
Surface Mount
Mounting Type
316 stainless steel with UL listing for wet location. Finish is stainless. This page does not add marine, coastal, or salt-air certifications beyond the listed alloy and wet-location listing.
Family range
This is a technical summary of the D700-SS316 range. Use Model Options above for pricing, availability, and ordering.
Installation
Dimensions shown in inches.
These notes summarize the specification drawing. They do not replace manufacturer installation instructions, a licensed electrician, or an engineer’s review of site conditions.
Project resources
Specification sheet
PDF · 3 pages
Download specification sheetInstallation / mounting drawing
Shown on this page. No separate installation PDF is currently published in the catalog.
Photometrics / IES
Contact Projekt Supply for lamp-specific performance / IES data.
Contact Projekt SupplyWarranty
Voltage varies by configuration. Not every D700-SS316 configuration supports every listed voltage.
Observed voltages: 120V-277V, 120V, 86V-265V
Lumens shown are nominal lamp output values provided for the listed D700-SS316 configurations.
| Configuration | Rated output | Voltage | CCT | Nominal lumens | Base |
|---|---|---|---|---|---|
| D700-L12-30K-SS316 | 12W | 120V-277V | 3000K | 1200 lm | G24 |
| D700-L12-40K-SS316 | 12W | 120V-277V | 4000K | 1225 lm | G24 |
| D700-L12-50K-SS316 | 12W | 120V-277V | 5000K | 1250 lm | G24 |
| D700-L20-30K-SS316 | 20W | 120V-277V | 3000K | 2400 lm | G24 |
| D700-L20-50K-SS316 | 20W | 120V-277V | 5000K | 2400 lm | G24 |
| D700-L6-30K-SS316 | 6W | 120V | 3000K | 480 lm | E26 |
| D700-L6-60K-SS316 | 6W | 120V | 6000K | 480 lm | E26 |
| D700-L6-RGBW-SS316 | 6W | 86V-265V | RGBW | 550 lm | E26 |
| D700-L9-27K-SS316 | 9W | 120V | 2700K | 550 lm | GU24 |
| D700-L9-40K-SS316 | 9W | 120V | 4000K | 800 lm | GU24 |
| D700-SS316 | 60W (MAX) | 120V-277V | — | — | E26 |
Use the Model Options table to complete the finish suffix.
D700-L12-30K-SS316
12W / 30K / Stainless Steel 316
The Model Options table above remains the ordering interface.
D700-SS316 RGBW · remote sold separately
4-ZONE
P-RMT-MR16-LED-4W-MC
~100 ft / 30 m
8-ZONE
P-RMT-LED-8ZONE-MC
~100 ft / 30 m
2.4 GHz RF
Dabmar Lighting Incorporated
Projekt Supply is the seller and authorized reseller. Dabmar Lighting Incorporated is the manufacturer.
Sold by Projekt Supply.
Choose D700-SS316 when the 316 stainless body is the reason to specify this family rather than fiberglass or cast aluminum.
